Industrial Battery Energy Storage for Zaporizhzhia: Sizing, Connection, and Pitfalls

Input Data: What We Need Before Sizing

Every BESS project starts with a load profile. For a metallurgical plant in Zaporizhzhia, the load often comes from electric arc furnaces and rolling mills – these have high peak demands and rapid load changes. An aero-engine manufacturer might have large test stands that run intermittently. A transformer producer will have welding and testing equipment that is cyclical.

We also need the tariff structure from Zaporizhzhiaoblenergo, including demand charges (UAH/kW) and energy rates. Without the actual 15-minute interval data, any capacity figure is a rough estimate. We can install temporary loggers to capture it if you don't have it.

Power and Capacity Sizing: From kW to MWh

Power sizing (kW) is driven by the peak you want to shave or the backup load you need to cover. For a typical 10 MW metallurgical load, shaving 2 MW for 1 hour requires a 2 MW / 2 MWh system. But if you have a 30-minute peak, a 1 MWh battery might suffice. The discharge duration is set by the application: demand charge management usually 1-2 hours, backup 2-4 hours.

Capacity (kWh) is then determined by the depth of discharge (DoD) – we use 90% DoD for LiFePO4 cells to get 6000+ cycles. For example, a 1 MW system with 1.5 MWh usable capacity would have a 1.67 MWh rated pack. We size for the 25-year life, factoring in ambient temperatures in Zaporizhzhia (down to -25°C), which is why we specify liquid cooling and IP55/C4 cabinets.

Connection Topology: How to Tie into the Grid

Most industrial sites in Zaporizhzhia are connected at 10 kV or 35 kV. The BESS can be connected on the low-voltage side (0.4 kV) for smaller systems, but above 500 kW you'll need a dedicated transformer and a 10 kV switchgear. Zaporizhzhiaoblenergo requires a technical conditions (TU) application, and they will dictate the point of common coupling and protection requirements.

We typically integrate the BESS behind the main transformer, paralleling with the existing load. For grid services like frequency regulation, you'd need a separate metering point. At 0.4 kV, you're limited to about 500 kW per feeder – beyond that, you'll need MV connection. We handle the entire process, from design to obtaining the TU approval.

What Goes Wrong If Sizing Is Bad

Undersizing the power means you don't shave the peak enough – your demand charge stays high, and the payback period stretches beyond 7 years. Oversizing wastes capital: a 2 MWh system that only cycles to 30% DoD will degrade faster due to shallow cycling and won't earn its keep.

If you ignore the load profile's shape – say, a metallurgical plant with a 15-minute peak from a furnace – a 1-hour battery will miss the peak entirely. Also, without proper thermal management, the battery will derate in summer, and in winter you'll see reduced capacity. And if you don't coordinate with Zaporizhzhiaoblenergo's protection settings, the BESS might trip on voltage dips, causing production stoppages.

Why Work with BESS Ukraine Engineering Group

We are a full-cycle EPC contractor for industrial storage from 50 kW to 5 MW. We've done feasibility studies for plants in this region, so we know the local grid codes and TU requirements. Our systems use LiFePO4 cells from Tier-1 suppliers (CATL and others), with liquid cooling and a robust BMS/EMS/SCADA.

We don't just supply hardware – we audit your facility, design the system, handle the connection application with Zaporizhzhiaoblenergo, install, and commission. After that, we provide service and monitoring. For residential systems, we refer you to SolarProm.com.ua, but for industrial BESS in Zaporizhzhia, call us: +380 44 339-50-20, or email engineering@bess.com.ua.
