Battery Energy Storage for a Woodworking Plant in Lviv: Engineering Breakdown

Input Data: What We Must Know Before Sizing

First, we need the plant's load profile: the kiln's power draw (typically 50–150 kW per kiln, with 2–4 kilns), the dust extraction system's starting current, and the base load from conveyors and compressors. Without a 15-minute interval load profile from the plant's existing metering, any capacity figure is a rough estimate.

Second, we need the outage history from Lvivoblenergo for the specific feeder. Lviv's industrial zones, especially the northern and eastern outskirts where woodworking plants cluster, experience 5–15 outages per year, with durations from 30 minutes to 4 hours. The grid voltage is 10 kV or 0.4 kV depending on the transformer; most plants have a 630 kVA transformer.

Third, we must know the kiln's thermal mass and the acceptable interruption time. In a typical drying schedule, a power loss of more than 15–20 minutes can cause uneven moisture content, leading to cracking or warping. That defines the autonomy requirement.

Power and Capacity Sizing: Kiln Cycle is the Boss

Start with the kiln load. If the plant runs two 100 kW kilns simultaneously, the BESS must deliver at least 200 kW for the duration of the outage. Add the dust extraction system's starting surge: a 75 kW fan can draw 6–8 times its rated current for a few seconds. That means the BESS inverter must handle a peak of 500–600 kW for 2–3 seconds, else the voltage collapses and the kiln controller resets.

Capacity is then autonomy time times average power. For a 2-hour outage at 200 kW, you need 400 kWh usable. But LiFePO4 cells shouldn't be discharged below 20% for cycle life, so nameplate capacity should be 500 kWh. Add a 20% margin for aging and temperature – Lviv winters are cold, and battery performance drops below 0°C unless the cabinet is heated. So we land at 600 kWh.

Payback is driven by avoided timber loss. A single ruined batch of oak can cost UAH 500,000–1,000,000. With 5 outages per year, that's UAH 2.5–5 million saved. The BESS, installed, costs around UAH 8–12 million. So payback is 2–4 years, not counting demand charge reduction or peak shaving.

Connection Topology: Where the BESS Sits

For most plants in Lviv, the connection is 0.4 kV. The BESS is installed on the secondary side of the plant's transformer, in parallel with the main switchboard. This allows islanding – when Lvivoblenergo drops the feeder, the BESS forms a local grid, powering the kilns and dust extraction. But you need a transfer switch that isolates the plant from the grid within 50 ms, else the BESS will back-feed the grid and risk safety.

If the plant has a 10 kV connection, a low-voltage BESS is still possible, but you must coordinate with Lvivoblenergo for protection settings. They require a dedicated metering point and a disconnect switch for the BESS. At 0.4 kV, this is simpler; you just need to comply with local rules and get approval from Lvivoblenergo.

The grid operator also has requirements for power quality. Your BESS must not inject harmonics or cause voltage flicker. That is non-negotiable for Lvivoblenergo – they have had issues with solar plants, so they are strict about inverter certifications.

What Goes Wrong If Sizing Is Off

If the BESS is undersized in power, the kiln won't start or the dust extraction will stall. A 100 kW BESS connected to a plant with two 100 kW kilns will trip on overload within seconds. The result: the kiln stops anyway, and you have wasted money.

If the capacity is too low, you might cover a 30‑minute outage but not a 2‑hour one. The BESS will shut down mid‑outage, and the timber batch is ruined. That is the worst case – you get a false sense of security.

If you ignore the starting surge, the inverter's current limit will cause the voltage to sag. That can reset the kiln's PLC, which may require a manual restart and re‑verify the drying schedule, adding hours of downtime.

If you oversize, you pay too much upfront. A 1 MWh BESS for a 200 kW plant is overkill – the payback extends to 6–7 years. A proper load profile and outage data prevent this.

Why This Combination Is Unique: Lviv + Woodworking

Lviv's industrial mix includes IT, data centres, furniture, and food processing. Data centres have generators and UPS – they don't need BESS for outages. Furniture plants, however, have kilns and dust extraction – process loads that are sensitive to power loss. Lviv's grid, managed by Lvivoblenergo, has aging infrastructure, especially in industrial zones where woodworking plants are located. Outages are frequent, and the grid voltage can fluctuate.

Woodworking plants also have dust extraction – a safety system. If dust extraction stops, the kiln must stop, else dust accumulates and creates an explosion risk. So a BESS that only covers the kiln but not the dust extraction is a safety hazard. That is why the sizing must include both.

Finally, Lviv's climate – cold winters and hot summers – affects battery performance. Outdoor cabinets need heating and cooling. The BESS must be specified with a thermal management system that handles -25°C to +35°C, which is standard for our outdoor cabinets.
