3 MW Battery Energy Storage: Engineering for Industry

What breaks or costs first in industrial power

In an energy-intensive plant, the first pain is demand charges – you pay for the highest 15-minute peak, often 30–50% of your bill. Then comes balancing market penalties if you can't follow your forecast. Transformers and cables age faster when they see repeated high loads, and a single voltage sag can halt a production line, costing more than the storage itself.

Without storage, you have two options: pay the utility or buy a spinning reserve. Both are recurring costs. Storage is the only one that can also earn revenue.

Power vs capacity: choosing the C-rate

Power is the rate of work (kW), capacity is the total work stored (kWh). The ratio is the C-rate. A 3 MW, 6 MWh system has a C-rate of 0.5C – it can deliver full power for 2 hours. At 12 MWh it's 0.25C – 4 hours.

For peak shaving and balancing, 0.5C is common because you need quick response. For arbitrage (buying low, selling high), lower C-rate may be cheaper per kWh. But don't oversize capacity – it adds cost without revenue if you can't cycle it.

Voltage class and connection for 3 MW

At 3 MW, 0.4 kV is possible but losses are high and switchgear gets big. Usually we connect at 10 kV (or 6/35 kV) via a transformer. The BESS is a containerized unit with an internal transformer that steps up from the battery voltage (typically 1000–1500 V DC) to 10 kV AC.

Connection is either behind the meter (parallel to your load) or at the substation for grid services. Grid connection requires a protection scheme and metering – we handle that in the design.

Footprint and siting: cabinet or container

A 3 MW BESS can be a set of outdoor cabinets (IP55, with liquid cooling) taking about 30–40 m², or a 20 ft container if you need more capacity or indoor protection. Indoor rooms are possible but need ventilation and fire suppression – we usually avoid that for LiFePO4 because outdoor is safer and cheaper.

Site requirements: concrete pad, access for a crane (container), a few meters from the main switchgear, and a place for the transformer. In industrial zones, that's often available.

What a 3 MW system costs (honest numbers)

CAPEX for a 3 MW, 6 MWh system typically runs $1.2–1.8 million, excluding civil works and grid connection. That's $200–300 per kWh. For 12 MWh, it's $2.0–3.0 million because the battery is the dominant cost.

What moves the price: cell chemistry (LiFePO4 is standard), cooling type (liquid vs air), container vs cabinets, and the EMS/SCADA sophistication. Without a load profile and tariff analysis, any payback figure is rough – but we've seen 4-7 years in Ukraine with current tariffs.
